Products Description
|
Basic description
|
||||
|
Parameter
|
Description
|
|||
|
Display
|
9 inch TFT, with touch screen.
|
|||
|
Drive gas
|
Gas type
|
O2 or Air
|
||
|
Inlet pressure
|
280-600 kPa.
|
|||
|
Max flow
|
≤ 120 L / min.
|
|||
|
Operating Mode
|
VCV,PCV,SPONT,Manual，Demo
|
|||
|
Waveform
|
Waveform:
Pressure,Flow-rate,Volume Loop:PV loop, PF loop,FV loop |
|||
|
Safety Pressure
|
System pressure does not exceed 6 KPa.
|
|||
|
Battery Type
|
Li-ion,work time more than 2 hours
|
|||
|
Parameters setting range
|
||
|
Parameter
|
description
|
|
|
Tidal volume
|
Range: 20 - 1500ml; Increment: 1 mL;
|
|
|
Respiratory rate
|
Range: 1 ~ 100 bpm;
|
|
|
Inspiratory time
|
Range: 0.1 ~ 10.0 s
|
|
|
Respiratory ratio
|
Range: 9.9:1 to 1:9.9
|
|
|
Percentage of inspiratory pause
|
Range: 0 to 50%
|
|
|
PEEP
|
Range: OFF, 3 ~ 20 cmH2O
|
|
|
Pressure Support
|
Range: 0 ~ 60 cmH2O
|
|
|
Pressure Control
|
Range: 5 ~ 60 cmH2O
|
|
|
Flow trigger
|
Range: 0.5 ~ 20L/min
|
|
|
Pressure Trigger
|
Range: -1 ~ -20 cmH2O
|
|
|
PSV Insp Termination Level
|
25%.
|
|
