It has a wide range of clinical applications, such as spine, trauma, joint orthopedics, pain, rehbilitation, general surgery, urology, gastroenterology, plastic surgery, onclogy, etc., provide the best solutions of diagnosis and treatment for you.
| HF & Mobile C-arm with flat pannel: Able for Fluorosocpy & Radiography | ||||||
| Model | FTL-3360A | FTL-3360B | FTL-3360C | FTL-3360D | FTL-3360E | FTL-3360F |
| flat panel detector size | 1024*1024 | 1024*1024 | 1024*1024 | 1344*1344 | 1344*1344 | 1344*1344 |
| Operation method | Manual | 3-way electric | four-way electric | Manual | 3-way electric | four-way electric |
| Leakage radiation dose | 0.002mGy/h. our country require 1.0mGy/h | 0.002mGy/h. our country require 1.0mGy/h | 0.002mGy/h. our country require 1.0mGy/h | 0.002mGy/h. our country require 1.0mGy/h | 0.002mGy/h. our country require 1.0mGy/h | 0.002mGy/h. our country require 1.0mGy/h |
| Flat pannel | France Thales Plate:single A-Si TFT+photodiode plate Scintillator: Csl |
France Thales Plate:single A-Si TFT+photodiode plate Scintillator: Csl |
France Thales Plate:single A-Si TFT+photodiode plate Scintillator: Csl |
France Thales Plate:single A-Si TFT+photodiode plate Scintillator: Csl |
France Thales Plate:single A-Si TFT+photodiode plate Scintillator: Csl |
France Thales Plate:single A-Si TFT+photodiode plate Scintillator: Csl |
| X-ray tube | Italy IMD Technology,rotating anode, dual focus 0.3/0.6mm | Italy IMD Technology,rotating anode, dual focus 0.3/0.6mm | Italy IMD Technology,rotating anode, dual focus 0.3/0.6mm | Italy IMD Brand,rotating anode, dual focus 0.3/0.6mm | Italy IMD Brand,rotating anode, dual focus 0.3/0.6mm | 进口球馆 Italy IMD Brand,rotating anode, dual focus 0.3/0.6mm |
| X-ray generator | 5kw, 120kv, 40kHz | 5kw, 120kv, 40kHz | 5kw, 120kv, 40kHz | 5kw, 120kv, 40kHz | 5kw, 120kv, 40kHz | 5kw, 120kv, 40kHz |
| Anode thermal capacity | 150KJ/200kHu | 150KJ/200kHu | 150KJ/200kHu | 150KJ/200kHu | 150KJ/200kHu | 150KJ/200kHu |
| Fluoroscopy | 40-120kv, 0.5-10mA | 40-120kv, 0.5-10mA | 40-120kv, 0.5-10mA | 40-120kv, 0.5-10mA | 40-120kv, 0.5-10mA | 40-120kv, 0.5-10mA |
| Radiography | 20-80mA, max. 100mA | 20-80mA, max. 100mA | 20-80mA, max. 100mA | 20-80mA, max. 100mA | 20-80mA, max. 100mA | 20-80mA, max. 100mA |
| Image Storage | Thousands of images stored | Thousands of images stored | Thousands of images stored | Thousands of images stored | Thousands of images stored | Thousands of images stored |
| Dicom 3.0 | Included | Included | Included | Included | Included | Included |
| PACS | compatible | compatible | compatible | compatible | compatible | compatible |
| Monitor | one 24" LCD monitor | one 24" LCD monitor | one 24" LCD monitor | one 24" LCD monitor | one 24" LCD monitor | one 24" LCD monitor |
| Printer | with | with | with | with | with | with |
| Workstation | with | with | with | with | with | with |
*Dynamic flat-panel detector
Csl dynamic flat-panel detector rectangular image, high definition, no distortion
*X-ray generator
Originated from Italian packaging technology, and improved and innovated, there is no need to worry about rays leakage and oil leakage. High-frequency inverter power supply and filament board ensure the stability of X-ray generator operation. The rays leakage index detected by authoritative departments is superior, foar lower than National standard regulations.
*DAP dose monitoring (optional)
Imported DAP is used to measure the actual value of radiation dose throughout the process, to ensure teh safety and controllability during using.
*Dual laser postitioning with time-delay of function
More accurately, faster positioning, and higher efficiency, ensuring error-free operation in the busy operating room and assisting you with easy positioning.
*10.4 inch large screen color LCD touch control screen
It can be be rotated 180º, which is convenient for operation at different stations, moisture-proof, rust-proof and corrosion-resistent, ensureing more accurately faster positioning and higher efficiency.
*Full parameter color LCD touch remote control (optional)
The full-parameter remote control can meet the special useness requirement of long distance and compartment etc.
Fatali Medical Technology Foshan Co.,Ltd is a 21 years professional experience medical equipment supplier.
