Suitable to do X ray for small and skinny people or small animals;
Fully independently developed, small in size, light in weight, 8-inch touchscreen interface, easy to operate
Small focus, clear imaging
With DROC processing software; Supports multiple languages;
The process is simple and convenient; Compliant with the DICOM3.0 protocol;It can interconnect and communicate with PACS; High quality image effects;
Customized interface process; Support for touch screen.
Long battery life, capable of taking over 100 shots when fully charged.
|
Project |
800W Portable X Ray Specification |
|
|
Charger |
Input |
mono-phase，AC power 220V±10% |
|
Frequency |
50Hz/60Hz±1Hz |
|
|
Output |
25.2 VDC ，1.5A |
|
|
Battery |
22.2V（polymer lithium ion），5000mAh |
|
|
kV |
40 -85 kV (step:1 kV ) |
|
|
mA |
1- 16mA (step:1 mA ) |
|
|
X-ray release time range |
0.03-0.20secs（step: 10millisecond） 0.010-4.00secs（step: 50millisecond） |
|
|
Screen |
8” inches (resolution: 1280x800) IPS |
|
|
X-ray tube |
Model |
|
|
Inherent filter |
0.5mm AL |
|
|
Focus point |
0.8X0.8mm |
|
|
CPU |
8G/16G，256GeMMC, WIFI6 |
|
|
Dimension |
280mm x 155mm x 65mm （length×width×height） |
|
|
Weight |
2.8kg±5% |
|
Tell us about your needs — we’ll recommend the best configuration + DR panel combo for your workflow. We have 23 years of manufacturing experience — you’re in good hands.
